Schneider A9D31625 Acti 9 iDPN N Vigi RCBO 1P+N 25A C Curve 6kA 30mA

range:Acti 9 product name:Acti9 iDPN Vigi product or component type:Residual current breaker with overcurrent protection (RCBO) device short name:IDPN N Vigi device application:Distribution poles description:1P + N number of protected poles:1 neutral position:Left In rated current:25 A network type:AC trip unit technology:Thermal-magnetic curve code:C earth-leakage sensitivity:30 mA earth-leakage protection time delay:Instantaneous earth-leakage protection class:Type AC breaking capacity:6000 A Icn at 220…240 V AC 50 Hz conforming to EN/IEC 61009-2-1 suitability for isolation:Yes conforming to EN/IEC 60947-2 device location in system:Outgoer network frequency:50 Hz Ue rated operational voltage:220…240 V AC 50 Hz magnetic tripping limit:5…10 x In residual current tripping technology:Voltage independent limitation class:3 conforming to EN/IEC 61009-2-1 Ui rated insulation voltage:400 V AC 50 Hz Uimp rated impulse withstand voltage:4 kV contact position indicator:Yes control type:Toggle local signalling:ON, OFF, fault trip mounting mode:Clip-on mounting support:DIN rail comb busbar and distribution block compatibility:Top or bottom: YES 9 mm pitches:4 net weight:125 g colour:White mechanical durability:20000 cycles electrical durability:10000 cycles wire stripping length:15 mm for top or bottom connection tightening torque:2 N.m top or bottom earth-leakage protection:Integrated standards:EN/IEC 61009-2-1 IP degree of protection:IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529 pollution degree:3 overvoltage category:III conforming to IEC 60364 electromagnetic compatibility:8/20 µs impulse withstand, 250 A conforming to EN/IEC 61009-2-1 tropicalisation:2 conforming to IEC 60068-1 Package 1 Weight:209.0 g Package 1 Height:4 cm Package 1 width:8 cm Package 1 Length:10 cm

Schneider A9D31625 Acti 9 iDPN N Vigi RCBO 1P+N 25A C Curve 6kA 30mA
