Kontaktor SCHNEIDER TESYS D 3P 9A AC-3 220VAC- LC1D09M7

TESYS D CONTACTOR 3P(3NO) AC3 440V 9A 220V AC COIL SCHNEIDER ELECTRIC – LC1D09M7
“[Deskripsi]
Kontaktor untuk mengontrol motor hingga 150 A (75 kW / 400 V).
Kontaktor TeSys D dan kontaktor pembalik tersedia dari 9 A hingga 150 A (motor induktif), dan dari 20 A hingga 200 A (beban resistif) dalam versi 3 kutub dan 4 kutub.

[Spesifikasi]
1.product or component type : Contactor
2. device short name : LC1D
3. contactor application :
-Resistive load
-Motor control
4. utilisation category :
-AC-4
-AC-1
-AC-3
5. poles description : 3P
6. power pole contact composition : 3 NO
7. [Ue] rated operational voltage :
-Power circuit: <= 690 V AC 25…400 Hz
-Power circuit: <= 300 V DC
8. [Ie] rated operational current :
-9 A (at <60 °C) at <= 440 V AC AC-3 for power circuit
-25 A (at <60 °C) at <= 440 V AC AC-1 for power circuit
9. control circuit type : AC at 50/60 Hz
10. [Uc] control circuit voltage : 220 V AC 50/60 Hz
11. auxiliary contact composition : 1 NO + 1 NC
12. [Ith] conventional free air thermal current :
-25 A (at 60 °C) for power circuit
-10 A (at 60 °C) for signalling circuit
13. Irms rated making capacity :
-250 A at 440 V for power circuit conforming to IEC 60947
-140 A AC for signalling circuit conforming to IEC 60947-5-1
-250 A DC for signalling circuit conforming to IEC 60947-5-1
14. rated breaking capacity : 250 A at 440 V for power circuit conforming to IEC 60947
15. height : 77 mm
16. width : 45 mm
17. depth : 86 mm
18. net weight : 0.32 kg”
